QIJIANG GEARBOX TRANSMISSION ASSEMBLY QJGT-6TS900
- FOB Price:negotiated
- Min.Order Quantity:1unts
- Supply Ability:1000unit/units per month
- Port:SHANGHAI,SHENZHEN,GUANGZHOU,BEIJING,URUMCHI
- Delivery mode: by air, by sea, by international courier, etc.
Product detail
| Brand Name:QJGT |
Part Number:6TS900 |
Place of origin:QIJIANG |
| Part Name:Gearbox assembly |
Machine:Truck |
Packaging&delivery
| Packaging Detail:wooden box or carton |
| Delvery Detail:two days after payment. |
Product description
QIJIANG GEARBOX TRANSMISSION ASSEMBLY QJGT-6TS900
| MODEL |
6TS900 |
| Technology type | Single intermediate shaft synchronizer mechanical transmission |
| Gear number | 6 forward, 1 backward |
| Installation length |
620mm |
| Maximum input torque |
1000N.m |
| Lubricating oil quantity |
13L |
| Center distance | 154mm |
| Weight |
225KG |
| Maximum applicable load |
25T |
| Applicable engine input power |
150-210KW |
| Optional add-on | hand brake | power takeoff | part-time case | | | | |
| Manipulating type | manual direct | manual remote | AMT | | | | |
| Recommended configuration clutch housing |
SAE1# |
| Applicable emission standards | G5 | G4 |
| Adaptation model, logistics | vehicle truck |
| Gear position and gear ratio |
| First gear | Second gear | Third gear | Fourth gear | Five gear | Six gear | Reverse gear |
| L | H | L | H | L | H | L | H | L | H | L | H | L | H |
| 9.01 | 5.24 | 3.22 | 2.20 | 1.50 | 1.00 | 8.30 |
| 7.03 | 4.09 | 2.45 | 1.50 | 1.00 | 0.81 | 6.48 |
| 6.98 | 4.06 | 2.74 | 1.89 | 1.31 | 1.00 | 6.43 |
If you are interested,please send me an EMAIL,or contact us by WHATAPP or WECHAT.
